A token matcher is built to be forgiving. It scores a pair of records by how much rare word mass they share, so it finds the real pairs even when the spelling drifts or the word order changes. That same forgiveness lets a few wrong pairs through: two different workshops that happen to share a common surname, a generic trade word, or a venue name. Retrieval gets you the candidates that look alike. The job left over is to throw out the ones that look alike but are not the same.
That job is calibration. You take a few hundred pairs, label each one by hand as a true match or not, train a small model on the features of those pairs, and use it to score every other pair. The model gives each pair a probability of being a true match. Then you decide where to draw the line.
This article walks the whole loop on the workshop register data, and spends most of its length on the decision that has no default answer: where to draw that line depends on what you do with the linked data next.
The data
Two tables carry the example. workshop_register is a
clean guild roll of 1,052 woodworking workshops;
workshop_listings is a messier external directory of 894
entries, most of which point back to a register row through their
actual_link column. We searched one against the other and
got candidate pairs. Some are right, some are not.
The labelled set ships ready to use.
match_labels_example holds 931 candidate pairs (two rows
each, one for the listing and one for the register row it was paired
with), with an equal column that marks each pair as a true
match (1) or a false one (0). It is the frozen
output of the manual labelling loop shown below: 711 of the pairs are
true, 220 are false, and the false ones cluster in the hard cases,
workshops that share a name but not an owner.
data(workshop_register)
data(workshop_listings)
data(match_labels_example)
# two rows per pair, so count distinct pairs
as.data.table(match_labels_example)[, .(pairs = uniqueN(match_id)), by = equal]
#> equal pairs
#> <int> <int>
#> 1: 1 711
#> 2: 0 220We rebuild the search so we have a live match result to work from. A loose threshold keeps the leaky candidates in, which is what we want here: the filter, not the threshold, is what removes them.
strat <- search_strategy(
workshop ~ normalize_text() + word_tokens(min_nchar = 3),
proprietor ~ normalize_text() + word_tokens(min_nchar = 2),
block_by = c("postcode_area", "trade"),
threshold = 0.30
)
m <- search_candidates(
workshop_listings, workshop_register,
base_id = "listing_id",
target_id = "reg_no",
strategy = strat
)Why retrieval is not enough
Look at the score distribution split at the threshold. A healthy chunk of the mass sits just above the cut, in the borderline band where true and false pairs are mixed together. No single score cleanly separates them, which is the whole reason a trained filter earns its keep.
ov <- summarise_matches(m, threshold = 0.5)
ov
#>
#> ── Match_Overview (candidates) ─────────────────────────────────────────────────
#> n_pairs_or_groups: "965" n_records_involved: "1461"
#> coverage: base=NA target=NA
#> score summary
#> min: 0.300
#> q1: 0.667
#> median: 0.808
#> mean: 0.828
#> q3: 1.000
#> max: 1.000
#> candidates-per-record (top 5)
#> 1 candidate(s): 564 record(s)
#> 2 candidate(s): 68 record(s)
#> 3 candidate(s): 79 record(s)
#> 4 candidate(s): 7 record(s)
#> ! 12.0% of base records have >= 3 candidate matches; consider `max_candidates` or raising threshold.
#> ! median top-1 vs top-2 score gap is 0.000; matches are weakly decisive, consider raising threshold or `feedback_strength`.A concrete leak: a listing for one “Walker Joinery” gets paired with a different Walker Joinery in the same postcode area, run by a different person. Both are real workshops. The shared surname and trade put them in the same block and gave them a respectable score. Only the surrounding detail tells them apart, and that is exactly the signal a feature table exposes.
Features: what makes a pair convincing
match_features() turns each candidate pair into one row
of numbers a model can learn from. It needs the strategy and both source
tables so it can recompute the per-pair detail.
feats <- match_features(
m, strat,
base = workshop_listings, id = "listing_id",
target = workshop_register, target_id = "reg_no"
)
dim(as.data.table(feats))
#> [1] 965 46That is one row per candidate pair and several dozen columns. You rarely read them by hand; the model does. But it helps to know the three groups they fall into, because they mirror how a person decides whether two records are the same workshop. One column from each group, for the first few pairs:
as.data.table(feats)[, .(match_id, score,
matched = m_workshop_1,
reg_extra = f_proprietor_1,
list_extra = s_workshop_1,
rivals = cnt)] |>
head()
#> match_id score matched reg_extra list_extra rivals
#> <int> <num> <num> <num> <num> <int>
#> 1: 1 1 0.5908422 NA NA 2
#> 2: 2 1 0.5908422 NA NA 2
#> 3: 3 1 1.0000000 0.4713661 NA 1
#> 4: 4 1 1.0000000 NA NA 1
#> 5: 5 1 1.0000000 NA NA 1
#> 6: 6 1 1.0000000 NA NA 1-
The words that caused the match
(
m_workshop_*,m_proprietor_*). The words the two records share, each weighted by how rare it is. A shared rare surname is strong evidence; a shared “joinery” is weak. This is the positive signal. -
The words only one side had (
f_*for the register side,s_*for the listing side). Surplus words the other record never mentions. A pair where each side carries several unexplained words is weaker than one where the words line up. -
The shape of the block (
cnt,icnt,ipos,scnt,rcnt). How many register rows competed for this listing, and where this pair ranked among them. A pair that won against three rivals is a different proposition from one that was the only candidate.
Most of these columns are mostly empty, and that is expected rather
than a problem. A slot like f_proprietor_2 holds the
second surplus word on the register side; a pair with no second
surplus word leaves it NA. An NA here means
“this pair had nothing for that slot”, not a value that went missing.
fit_filter() reads NA as a plain zero (its
na_fill argument), so an absent word contributes nothing
instead of breaking the fit.
The block-shape group only carries signal when listings actually face competing candidates. In this data about one listing in five draws more than one register row, which is enough for those features to matter.
Label a sample (the real loop)
The labelled set did not appear from nowhere. You build it by sampling pairs, exporting them to a CSV, marking each one by hand, and reading the result back. joinery samples where the decision is hardest, in the borderline band and in blocks where several candidates compete:
sample <- sample_matches(m, mode = "borderline", n = 200,
stratify_by = "stage", expand_to_block = TRUE)
export_for_labelling(sample, "to_label.csv") # edit the equal column by hand
labels <- import_labels("to_label.csv") # read it back, ready to fitmatch_labels_example is exactly that output, frozen so
the rest of this article runs without a manual step. From here on we use
it directly.
Fit the filter
fit_filter() joins the features to the labels and fits a
logistic model. The default is a plain glm, which keeps the
baseline path free of extra dependencies. It reports how many labelled
rows it trained on and the class balance.
fm <- fit_filter(feats, match_labels_example, model = "logistic")
fm
#> <joinery::Filter_Model>
#> backend : glm
#> model_class : glm
#> predictors (42) : score, cnt, icnt, ipos, scnt, rcnt, r1, r2
#> ... +34 more
#> training_n : 442
#> class_balance : 0.756 (share of equal == 1L)
#> class_weighted : FALSEThe labelled set leans toward true matches (the class balance the
print reports). If the false pairs are the rare class you most want to
catch, pass class_weighted = TRUE to weight the two classes
evenly while fitting. We keep the plain unweighted fit here because it
already separates the classes well on this data.
If you prefer a tidymodels workflow, fit_filter() also
accepts a parsnip model spec or a workflows
object, and joinery_recipe() builds a recipe with the id
and outcome roles already tagged. Those packages stay in
Suggests, so the glm path above needs nothing
extra installed.
Choosing where to draw the line
This is the decision that matters, and the one with no universal answer.
apply_filter() scores every pair and, by default, picks
the threshold that best balances two quantities (Youden’s J). The first
is precision, the share of the pairs it keeps that are
really matches. The second is recall, the share of all
the true matches it manages to keep. On this data the balanced line
lands near 0.82, and it favours precision: of the pairs it keeps almost
all are real, but it drops a number of true matches to get there.
cm_balanced <- apply_filter(feats, fm)
cm_balanced
#>
#> ── Calibrated_Matches ──────────────────────────────────────────────────────────
#> <joinery::Calibrated_Matches>
#> threshold : 0.7237 (method: youden_j)
#> n_rows : 965
#> predicted_tp == 1: 616
#> predicted_tp == 0: 349
#> tp_prob quantiles: 0.000 / 0.016 / 0.972 / 0.998 / 1.000You can ask for a different operating point. The
threshold_rule argument trades the two kinds of error
against each other directly:
-
"target_recall"keeps the strictest line that still recovers a set fraction of the true matches. Use it when missing a real link is the expensive mistake. -
"cost_weighted"minimisescost_ratio * (missed links) + (wrong links). Acost_ratioabove 1 says a missed link hurts more than a wrong one.
cm_recall <- apply_filter(feats, fm, threshold_rule = "target_recall",
target_recall = 0.95)
cm_recall
#>
#> ── Calibrated_Matches ──────────────────────────────────────────────────────────
#> <joinery::Calibrated_Matches>
#> threshold : 0.6886 (method: target_recall)
#> n_rows : 965
#> predicted_tp == 1: 620
#> predicted_tp == 0: 345
#> tp_prob quantiles: 0.000 / 0.016 / 0.972 / 0.998 / 1.000Both are defensible. Which one is right is not a property of the matcher. It is a property of the question you are about to ask of the data.
The error you should fear depends on the analysis
A false positive is an over-link: two records fused that belong to different workshops. A false negative is a missed link: a true pair the filter rejected. Every analysis pays for these two mistakes differently, and sometimes in opposite directions.
| Downstream analysis | Over-link (false positive) does | Missed link (false negative) does | Which to favour |
|---|---|---|---|
| How many workshops are active in an area | merges two real firms, undercount | splits one firm in two, overcount | balanced: the two biases partly cancel in a level |
| Entry, exit, and survival over time | erases one firm’s birth and another’s death, churn looks too low | invents a phantom exit and re-entry, churn looks too high | no easy call: both directions bias, oppositely |
| Attaching an external variable to each firm | wrong record linked, wrong values, measurement error | row dropped; selection bias if hard-to-link firms differ | precision, unless non-linkage is itself informative |
| Following the same firms before and after an event | another firm’s outcomes leak into the trajectory | a treated firm drops out, lost units and attrition | recall, while watching for contamination |
| Cleaning a register to count establishments | erases a real establishment, deflates the count | keeps a duplicate, double-counts | a conservative merge, precision |
The first row is the gentle case. If you only want a count of distinct workshops in a level, over-linking and under-linking push the number in opposite directions and partly cancel, so a balanced cut is fine.
Why entry and exit is the hard one
Now follow the same workshops across years instead of counting them
once. The package ships workshop_panel, a pooled multi-year
version of the same universe (847 rows, 320 firms, 2019 to 2023), with
the cross-year links as ground truth. Linking it lets you read each
firm’s birth year, death year, and how long it survived. Here the two
errors do not cancel. They bias the answer in opposite directions, and
there is no operating point that is safe for both.
- Over-link. Fuse two distinct “Walker Joinery” workshops into one firm. That single wrong link erases one firm’s entry and another’s exit. The merged firm looks longer-lived than either real one, and the area’s churn looks lower than it is. A recall-favouring cut admits exactly these same-name pairs, so a recall-favouring cut understates churn and overstates survival.
- Under-link. A workshop that relocated, or whose name drifted, is not linked across the move. That manufactures a fake exit in one year and a fake entry the next. Churn looks too high, survival too short. A precision-favouring cut drops these borderline cross-year links, so a precision-favouring cut overstates churn and understates survival.
So for an entry-and-exit study you cannot reach for a default. The project’s usual habit of favouring recall is right for a within-table cleanup where a later, looser pass re-bridges what an early strict pass missed. For a churn estimate that same habit quietly bakes in a bias toward low turnover. The honest options are to pick the bias you can defend and correct for, or to stop hard-thresholding at all and carry the probability forward (the “Beyond a single line” section below). The full multi-year workflow, and reading entry and exit off the resulting entities, is the article on matching across years and sources.
Apply the chosen line
Once you have an operating point, apply_filter() writes
a tp_prob (the probability the pair is a true match) and a
predicted_tp flag onto the result. Pass the original
matches in matches = to broadcast both onto every row of
the match table, ready to feed the rest of your pipeline:
cm <- apply_filter(feats, fm, matches = m)
head(as.data.table(cm@matches)[, .(match_id, source, score, tp_prob, predicted_tp)])
#> match_id source score tp_prob predicted_tp
#> <int> <char> <num> <num> <int>
#> 1: 1 base 1 0.006985289 0
#> 2: 1 target 1 0.006985289 0
#> 3: 2 base 1 0.006985289 0
#> 4: 2 target 1 0.006985289 0
#> 5: 3 base 1 0.979645996 1
#> 6: 3 target 1 0.979645996 1The two operating points keep different sets. The balanced cut keeps the pairs it is sure about and rejects almost every false one; the recall-favouring cut keeps nearly all the true matches at the cost of letting a few more false ones through. Sliced by which kind of name collision they came from, the balanced filter rejects every one of the planted same-name-same-block traps and the large majority of the register duplicates. The mistakes it removes are exactly the ones that would corrupt a firm count or a churn estimate.
Evaluate honestly
A filter that reports a probability is only useful if that
probability means what it says. calibrate() checks this. It
returns a reliability table (in each probability band, does the observed
share of true matches line up with the predicted probability), a Brier
score and log-loss (lower is better), and the full threshold sweep.
cal <- calibrate(cm_balanced)
cal
#>
#> ── Filter_Calibration ──────────────────────────────────────────────────────────
#> n_eval: "442" class_balance: "0.756"
#> threshold: "0.7237" brier: "0.0284" log_loss: "0.0870"
#> confusion
#> equal=0 pred=0: 105 pred=1: 3
#> equal=1 pred=0: 17 pred=1: 317
#> ! filter was fit on only 442 labelled pairs; consider expanding the labelled sample to >= 500 for stable calibration.
rel <- as.data.frame(cal@reliability)
plot(rel$mean_pred, rel$obs_pos,
type = "b", pch = 19,
xlim = c(0, 1), ylim = c(0, 1),
xlab = "Mean predicted probability",
ylab = "Observed share of true matches",
main = "Reliability")
abline(0, 1, lty = 2)
Points on the dashed line mean the probabilities are honest: pairs
the model calls 90% likely are true about 90% of the time. Had we
trained on only a couple of hundred labels, calibrate()
would have added a low-sample warning, because the reliability estimate
itself gets noisy when the labelled set is small. This is the point
where joinery goes past simply counting hits and misses: it tells you
whether to trust the number before you build a threshold on it.
Beyond a single line
A global threshold is the simplest tool, not the only one. Ordered from cheapest to most careful:
- One global threshold. What we did above. Pick balanced, recall-favouring, or precision-favouring from the sweep, guided by the downstream table.
-
A threshold per stage. If you matched in stages,
the exact-match stage scores its pairs at 1.0 and is almost never wrong.
Threshold only the fuzzy stages. The
stagecolumn is on every result, so this is usually the cheapest large gain. -
Carry the probability, do not cut. Keep
tp_probas a link weight instead of a yes-or-no, and let the uncertainty flow into the downstream estimate, for instance by weighting observations or by imputing over uncertain links. This is the rigorous answer for the entry-and-exit case, where any hard cut bakes in a directional bias. -
A review queue. Accept the confident matches,
reject the confident non-matches, and route the borderline band to a
person with
sample_matches(mode = "borderline"). The practical hybrid when the analysis is high-stakes and more labels are cheap to get.
Sanity-check: does the conclusion move with the cut?
Picking an operating point is a judgement call, so do not let the whole result rest on it silently. The cheapest insurance is to run your actual downstream analysis under more than one matching regime and see whether the answer holds.
A natural pair to compare is a strict, exact-only linkage against the permissive, calibrated one. Exact matching is almost never wrong, but it recovers only the easy cases and misses the harder ones: the movers, the drifters, the sound-alikes. If those hard-to-link workshops differ systematically from the easy ones, an exact-only sample is a selected sample, and an estimate built on it can be biased even though every link in it is correct. The permissive linkage recovers those harder cases, at the cost of admitting a few wrong links.
So compute the number you actually care about both ways. If the strict and permissive linkages give materially different answers, the gap is telling you that linkage error is moving your estimate, and you need to either defend the operating point or carry the uncertainty forward rather than hard-cut. If they agree, that agreement is real reassurance: the conclusion is robust to how permissive you were, and the choice of line stops being something to worry about.
Where to look next
- The matches this article cleans were built in the features article; start there for the search itself.
- The full multi-year workflow that the entry-and-exit example sketches, including how to read birth and death years off the linked entities, is the article on matching across years and sources.
- Carrying linkage uncertainty all the way into a downstream model, rather than thresholding, is on the roadmap beyond the 1.0 release.
